Homelab Infrastructure Platform

Overview

My homelab is more than a collection of services—it's a structured infrastructure platform designed with production principles in mind. Built over several years, it serves as both a learning environment and a practical hosting solution for personal projects and experiments.

The platform encompasses virtualization, storage, networking, monitoring, and secure remote access, all designed to work together as a cohesive system.

Features

• Proxmox Virtualization - Multiple isolated VMs and containers running on enterprise-grade hypervisor
• TrueNAS Storage - Centralized storage with snapshot-based data protection
• Tailscale Overlay Network - Secure remote administration without exposed ports
• Prometheus & Grafana Monitoring - Full observability with metrics, dashboards, and alerting
• Unifi Network Architecture - Segmented networking with controlled ingress
• Backup Infrastructure - Layered recoverability using snapshots and offsite backups

Technical Highlights

Virtualization Layer

Proxmox VE provides the compute foundation:

• Multiple VMs with dedicated resource allocations
• Container support for lightweight workloads
• Snapshot capability for safe experimentation
• Template-based provisioning for new services

Each workload runs in isolation, limiting blast radius when things go wrong and enabling independent lifecycle management.

Storage Architecture

TrueNAS handles persistent data:

• ZFS-based storage with data integrity guarantees
• Snapshot automation for point-in-time recovery
• Network storage accessible across all VMs
• Tiered storage approach separating critical and rebuildable data

The storage layer is designed around the principle that data protection is a workflow, not just a feature.

Network Design

Unifi networking gear provides:

• VLAN-based segmentation separating trust zones
• Firewall rules controlling inter-segment traffic
• Controlled ingress minimizing attack surface
• Management plane isolated from service traffic

Network architecture follows least-privilege principles—devices and services only have the access they need.

Secure Remote Access

Tailscale creates an overlay network for administration:

• No exposed management ports on the public internet
• Device-based authentication for access control
• End-to-end encryption for all management traffic
• Access from anywhere without VPN complexity

This pattern eliminates an entire category of attack surface while maintaining full operational capability.

Observability Stack

Prometheus and Grafana provide visibility:

• Metrics collection from all hosts and services
• Custom dashboards for infrastructure and application health
• Alert rules with Discord notification delivery
• Historical data for trend analysis and capacity planning

The monitoring stack enables proactive operations—catching issues before they become user-visible problems.

Architecture

graph TB
    subgraph internet [Internet]
        Users[Users]
        Admin[Admin Devices]
    end

    subgraph edge [Edge Layer]
        Cloudflare[Cloudflare DNS]
        VPS[VPS Ingress]
    end

    subgraph homelab [Homelab]
        subgraph network [Network Layer]
            Unifi[Unifi Router]
            Tailscale[Tailscale Mesh]
        end

        subgraph compute [Compute Layer]
            Proxmox[Proxmox Host]
            VMs[Service VMs]
            Containers[Containers]
        end

        subgraph storage [Storage Layer]
            TrueNAS[TrueNAS]
            Backups[Backup Storage]
        end

        subgraph observability [Observability]
            Prometheus[Prometheus]
            Grafana[Grafana]
            Alerts[Discord Alerts]
        end
    end

    Users --> Cloudflare --> VPS --> Unifi
    Admin --> Tailscale --> Proxmox
    Unifi --> VMs
    VMs --> TrueNAS
    VMs --> Prometheus --> Grafana --> Alerts
    TrueNAS --> Backups

Operations

Change Management

All changes follow a disciplined workflow:

• Snapshot before risky operations
• Test in isolation when possible
• Document changes and their rationale
• Monitor for unexpected effects after deployment

Incident Response

When issues occur:

• Alerts notify me via Discord
• Dashboards provide context for investigation
• Rollback capability enables quick recovery
• Post-incident review captures lessons

Capacity Planning

Monitoring data drives planning:

• Resource utilization trends over time
• Storage consumption projections
• Service demand patterns
• Upgrade decisions based on data, not guesswork

Lessons Learned

Building and operating this platform taught me:

• Isolation reduces complexity - Clear boundaries make troubleshooting tractable
• Documentation is operational - Future me needs to understand current me's decisions
• Monitoring enables confidence - Visibility allows bold changes with safety nets
• Security is architectural - Good design prevents problems better than patches

What's Next

The homelab continues to evolve:

• Improved inventory documentation and network mapping
• Enhanced backup destinations and retention policies
• Container orchestration exploration for stateless workloads
• Continued hardening based on security best practices

This platform serves as both a practical hosting environment and a laboratory for learning production infrastructure skills.
